| Product Image |
.jpg) |
| Model Name |
NS-1040 |
| Maximum Number of Licenses |
8 |
| Base License |
4 |
| Video Output |
HDMI or VGA |
| Output Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
| Decoding Capacity |
120fps @1080p or 240fps @720p (H.264/MPEG4; MJPEG/MxPEG is with limited support) |
| Recording Performance |
60 Mbps |
| Operating System |
Embedded Linux |
| Compression |
H.264, MPEG-4, MJPEG, MxPEG (depends on IP camera) |
| Remote Client |
Remote Live Viewer (Software), Remote Live Viewer (Web), iViewer (Mobile App) |
| Remote Client OS |
Windows XP (32-bit), Win7 (32 and 64-bit) |
| Mobile Client Platform |
iPhone, iPad, Android |
| HDD Bays |
1 x 3.5″ or 2 x 2.5″ |
| RAID Level |
0,1 |
| External Storage |
DAS |
| Ethernet Port |
2 x Gigabit Port, RJ-45 |
| External Ports |
5 x USB 2.0 |
| Audio |
One – way |
| Voltage |
DC 12V 4A |
| Power Consumption |
48W |
| Dimensions (H x W x D) |
262 x 137 x 300 mm |
| Weight (without HDD) |
2.5 kg (5.51lbs) |
| Temperature (Operating with HDD) |
Operating: 0° C ~ 40°C (32°F ~ 104°F) |
| Humidity (Operating) |
Operating: 5% ~ 95% |
| Supported Languages |
English, Croatian, Czech, Deutsch, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese (Brazil), Russian, Simplified Chinese, Traditional Chinese, Spanish, Swedish |
|
